FlexView FMA90 - control unit for level and flow measurement

雷达物位仪

Level, pump control,
Open channel flow measurement, data logging

Degree of protection of polycarbonate field housing;
and aluminum field housing: IP65/NEMA Type 4x;
Degree of protection of DIN rail housing: IP20;
Degree of protection of panel housing: IP65/NEMA Type 4 (at front,;
if mounted in cabinet door), IP20 (at rear, if mounted in cabinet door);
sensor recognition and parameter mapping;
of FMR10B/FMR20B/FMR30B/FMX21 sensors

100 … 230 VAC;
10.5 … 32VDC

-40 to +60 °C (-40 to +140 °F) (Type tested);
-35 to +60 °C (-31 to +140 °F) (approved by CSA)

HART

ATEX, CSA, EAC, JPN Ex, NEPSI, INMETRO

3.5" TFT touch display with backlight for onsite Operation,;
diagonal screen measurement 90 mm (3.5");
Resolution QVGA, 76,800 pixels (320 x 240);
16.7 million displayable colors, 24 bit color depth;
maximum character size and number of digits:;
max. 50 pixels or 13 mm with max. seven digits

Sensors: FMR10B, FMR20B, FMR30B, FMX21, FMU30

固体物位雷达

Level, pump control,;
open channel flow measurement, data logging

Degree of protection of polycarbonate field housing;
and aluminum field housing: IP65/NEMA Type 4x;
Degree of protection of DIN rail housing: IP20;
Degree of protection of panel housing: IP65/NEMA Type 4 (at front,;
if mounted in cabinet door), IP20 (at rear, if mounted in cabinet door);
sensor recognition and parameter mapping;
of FMR10B/FMR20B/FMR30B/FMX21 sensors

100 … 230 VAC;
10.5 … 32VDC

–40 to +60 °C (–40 to +140 °F) (Type tested);
–35 to +60 °C (–31 to +140 °F) (approved by CSA)

HART

ATEX, CSA, EAC, JPN Ex, NEPSI, INMETRO

3.5" TFT touch display with backligh for onsite Operation,;
diagonal screen measurement 90 mm (3.5");
Resolution QVGA, 76,800 pixels (320 x 240);
16.7 million displayable colors, 24 bit color depth;
maximum character size and number of digits:;
max. 50 pixels or 13 mm with max. seven digits

Sensors: FMR10B, FMR20B, FMR30B, FMX21, FMU30
