All the advantages of our new Micropilot FMR10B, FMR20B and FMR30B for Water and Wastewater, Mining, Minerals and Metals and utilities across all industries.
Level, pump control, open channel flow measurement, data logging
供电电压
100 … 230 VAC; 10.5 … 32VDC
环境温度
-40 to +60 °C (-40 to +140 °F) (Type tested); -35 to +60 °C (-31 to +140 °F) (approved by CSA)
通信
HART
证书和认证
ATEX, CSA, EAC, JPN Ex, NEPSI, INMETRO
特点
Degree of protection of polycarbonate field housing; and aluminum field housing: IP65/NEMA Type 4x; Degree of protection of DIN rail housing: IP20; Degree of protection of panel housing: IP65/NEMA Type 4 (at front,; if mounted in cabinet door), IP20 (at rear, if mounted in cabinet door); sensor recognition and parameter mapping; of FMR10B/FMR20B/FMR30B/FMX21 sensors
测量原理
雷达物位仪
特点/应用
Level, pump control, Open channel flow measurement, data logging
特点
Degree of protection of polycarbonate field housing; and aluminum field housing: IP65/NEMA Type 4x; Degree of protection of DIN rail housing: IP20; Degree of protection of panel housing: IP65/NEMA Type 4 (at front,; if mounted in cabinet door), IP20 (at rear, if mounted in cabinet door); sensor recognition and parameter mapping; of FMR10B/FMR20B/FMR30B/FMX21 sensors
电源/通信
100 … 230 VAC; 10.5 … 32VDC
环境温度
-40 to +60 °C (-40 to +140 °F) (Type tested); -35 to +60 °C (-31 to +140 °F) (approved by CSA)
通信
HART
证书和认证
ATEX, CSA, EAC, JPN Ex, NEPSI, INMETRO
选项
3.5" TFT touch display with backlight for onsite Operation,; diagonal screen measurement 90 mm (3.5"); Resolution QVGA, 76,800 pixels (320 x 240); 16.7 million displayable colors, 24 bit color depth; maximum character size and number of digits:; max. 50 pixels or 13 mm with max. seven digits
组件
Sensors: FMR10B, FMR20B, FMR30B, FMX21, FMU30
测量原理
固体物位雷达
特点/应用
Level, pump control,; open channel flow measurement, data logging
特点
Degree of protection of polycarbonate field housing; and aluminum field housing: IP65/NEMA Type 4x; Degree of protection of DIN rail housing: IP20; Degree of protection of panel housing: IP65/NEMA Type 4 (at front,; if mounted in cabinet door), IP20 (at rear, if mounted in cabinet door); sensor recognition and parameter mapping; of FMR10B/FMR20B/FMR30B/FMX21 sensors
电源/通信
100 … 230 VAC; 10.5 … 32VDC
环境温度
–40 to +60 °C (–40 to +140 °F) (Type tested); –35 to +60 °C (–31 to +140 °F) (approved by CSA)
通信
HART
证书和认证
ATEX, CSA, EAC, JPN Ex, NEPSI, INMETRO
选项
3.5" TFT touch display with backligh for onsite Operation,; diagonal screen measurement 90 mm (3.5"); Resolution QVGA, 76,800 pixels (320 x 240); 16.7 million displayable colors, 24 bit color depth; maximum character size and number of digits:; max. 50 pixels or 13 mm with max. seven digits
