微波限位栅接收器
Soliwave FDR56

©Endress+Hauser

颗粒固体的非接触式限位检测接收器

Soliwave FDR56微波限位开关接收器适用于非接触式限位检测,可安装在容器、导管、传动轴或自由落体轴中,也可安装在非金属容器外部进行测量,控制并计算各种类型的颗粒固体。可与Soliwave FQR56发射器配套使用。

此产品暂未在中国市场销售

  • 优势

    • 齐平式非接触式安装

    • 使用R 1-1/2-或1-1/2NPT-螺纹,安装方便

    • 电子外壳可360°旋转,可在安装后将设备调至最佳位置。

    • 机械部分结构坚固:
      - 无磨损;
      - 接液部分选用陶瓷传感器隔膜(可选);
      - 使用寿命长;
      - 免维护。

    • 接收器上可显示信号强度。

    • 直接连接电源(发射器与接收器可分开或配套使用)

    • 符合ATEX 1/2GD与IECEx标准。

  • 应用领域

    Soliwave微波限位开关适用于非接触式限位检测,可安装容器、导管、传动轴或自由落体轴中,也可安装在非金属容器外部进行测量,控制并计数各种类型的颗粒固体或袋状或盒状包装体等。 典型测量的颗粒固体包括:木屑、木粉与面粉,石膏、水泥与石灰,纸张及硬纸片,碎石与沙粒,常见的干粉。

特征和规格

返回

Details

  • 测量原理

    微波安全栅

  • 特点/应用

    接收器
    非接触式限位检测和流量监测
    检测、计数和物位测量
    物料传输点监测
    沉积物和污染检测和分析

    安装:
    非接触式安装(传输窗口)或前部齐平安装(接触式)

  • 特点

    最大量程100 m

  • 电源/通信

    85...253 VAC
    20...60 VDC/ 20...30 VAC

  • 环境温度

    -40...+70 °C
    (-40...+158 °F)

  • 过程温度

    非接触式安装:任意
    在安装范围内:
    -40 °C...+70 °C (-40 °F...+158 °F)
    带HT接头:
    最高+450 °C (+842 °F)

  • 过程压力(绝压)/最大过压限定值

    非接触式安装:任意
    在安装范围内:
    0.5 bar ... 6.8 bar (7.2 psi ... 99 psi),绝压
    带HD接头:
    最大+21 bar (+305 psi),绝压

  • 最小介质密度

    固体重量:> 10 g/l

  • 主要接液部件

    非接触式安装:
    非接液部件
    在安装范围内:
    316Ti或铝;
    PTFE或陶瓷

  • 过程连接

    1-1/2" R、1-1/2" G、1-1/2" NPT

  • 卫生型过程连接

    非接触式安装

  • 通信

    SPDT继电器
    固态继电器
    4 ... 20 mA

  • 证书和认证

    ATEX、CSA C/US、IEC Ex

  • 设计认证

    EN10204-3.1

  • 选项

    观视玻璃窗
    高温接头
    高温接头
    安装架
    FAR50、FAR51、FAR52、FAR53、FAR54、FAR55

  • 组件

    变送器:FQR56

  • 应用限制

    固体重量:< 10 g/l

文档/手册/软件

附件/备件

Nr
Order code
Specification
    • Order code 71125423

      电子插件

      Electronic module receiver. Non-hazardous area, relay, AC version. Compatible for devices that have been delivered until 30.04.2016. Usage: FDR56.

    • Order code 71125424

      电子插件

      Electronic module receiver. Non-hazardous area, relay, DC version. Compatible for devices that have been delivered until 30.04.2016. Usage: FDR56.

    • Order code 71125425

      电子插件

      Electronic module receiver. Non-hazardous area, 4-20mA, AC version. Usage: FDR56.

    • Order code 71125426

      电子插件

      Electronic module receiver. Non-hazardous area, 4-20mA, DC version. Usage: FDR56.

    • Order code 71125427

      电子插件

      Electronic module receiver. Non-hazardous area, solid-state-relay, AC version. Usage: FDR56.

    • Order code 71125428

      电子插件

      Electronic module receiver. Non-hazardous area, solid-state-relay, DC version. Usage: FDR56.

    • Order code 71125429

      电子插件

      Electronic module receiver. ATEX II 1/2D IP66 T102oC, relay, AC version. Compatible for devices that have been delivered until 30.04.2016. Usage: FDR56.

    • Order code 71125430

      电子插件

      Electronic module receiver. ATEX II 1/2D IP66 T102oC, relay, DC version. Compatible for devices that have been delivered until 30.04.2016. Usage: FDR56.

    • Order code 71125431

      电子插件

      Electronic module receiver. ATEX II 1/2D IP66 T102oC, 4-20mA, AC version. Usage: FDR56.

    • Order code 71125432

      电子插件

      Electronic module receiver. ATEX II 1/2D IP66 T102oC, 4-20mA, DC version. Usage: FDR56.

    • Order code 71125433

      电子插件

      Electronic module receiver. ATEX II 1/2D IP66 T102oC, solid-state-relay, AC version. Usage: FDR56.

    • Order code 71125434

      电子插件

      Electronic module receiver. ATEX II 1/2D IP66 T102oC, solid-state-relay, DC version. Usage: FDR56.

    • Order code 71125436

      电子插件

      Electronic module receiver. IECEx II 1/2D IP66 T102oC, relay, AC version. Compatible for devices that have been delivered until 30.04.2016. Usage: FDR56.

    • Order code 71125437

      电子插件

      Electronic module receiver. IECEx II 1/2D IP66 T102oC, relay, DC version. Compatible for devices that have been delivered until 30.04.2016. Usage: FDR56.

    • Order code 71125438

      电子插件

      Electronic module receiver. IECEx II 1/2D IP66 T102oC, 4-20mA, AC version. Usage: FDR56.

    • Order code 71125439

      电子插件

      Electronic module receiver. IECEx II 1/2D IP66 T102oC, 4-20mA, DC version. Usage: FDR56.

    • Order code 71125440

      电子插件

      Electronic module receiver. IECEx II 1/2D IP66 T102oC, Solid-state-relay, AC version. Usage: FDR56.

    • Order code 71125441

      电子插件

      Electronic module receiver. IECEx II 1/2D IP66 T102oC, Solid-state-relay, DC version. Usage: FDR56.

    • Order code 71258315

      电子插件

      Electronics receiver. CSA General Purpose, relay, AC version. Usage: FDR56.

    • Order code 71258316

      电子插件

      Electronics receiver. CSA General Purpose, relay, DC version. Usage: FDR56.

    • Order code 71258317

      电子插件

      Electronics receiver. CSA General Purpose, 4-20mA, AC version. Usage: FDR56.

    • Order code 71258318

      电子插件

      Electronics receiver. CSA General Purpose, 4-20mA, DC version. Usage: FDR56.

    • Order code 71258319

      电子插件

      Electronics receiver. CSA General Purpose, solid-state-relay, AC version. Usage: FDR56.

    • Order code 71258321

      电子插件

      Electronics receiver. CSA General Purpose, solid-state-relay, DC version. Usage: FDR56.

    • Order code 71258322

      电子插件

      Electronics receiver. CSA C/US Class II, Div. 1, Group E-G, relay, AC version. Usage: FDR56.

    • Order code 71258324

      电子插件

      Electronics receiver. CSA C/US Class II, Div. 1, Group E-G, relay, DC version. Usage: FDR56.

    • Order code 71258325

      电子插件

      Electronics receiver. CSA C/US Class II, Div. 1, Group E-G, 4-20mA, AC version. Usage: FDR56.

    • Order code 71258327

      电子插件

      Electronics receiver. CSA C/US Class II, Div. 1, Group E-G, 4-20mA, DC version. Usage: FDR56.

    • Order code 71258329

      电子插件

      Electronics receiver. CSA C/US Class II, Div. 1, Group E-G, solid-state-relay, AC version. Usage: FDR56.

    • Order code 71258330

      电子插件

      Electronics receiver. CSA C/US Class II, Div. 1, Group E-G, solid-state-relay, DC version. Usage: FDR56.

    • Order code 71324253

      Electronic insert D-AA1A, FDR56, V2

      Electronic module receiver. Non-hazardous area, relay, AC version. Compatible for devices that have been delivered from 01.05.2016 on. Usage: FDR56.

    • Order code 71324258

      Electronic insert D-AA1E, FDR56, V2

      Electronic module receiver. Non-hazardous area, relay, DC version. Compatible for devices that have been delivered from 01.05.2016 on. Usage: FDR56.

    • Order code 71324267

      Elektronikeinsatz D-AA1A, FDR56 (F34)

      Electronic module receiver. Non-hazardous area, relay, AC version. Usage: FDR56.

    • Order code 71324268

      Elektronikeinsatz D-AA1E, FDR56 (F34)

      Electronic module receiver. Non-hazardous area, relay, DC version. Usage: FDR56.

    • Order code 71324271

      Electronic insert D-AA2A, FDR56 (F34)

      Electronic module receiver. Non-hazardous area, 4-20mA, AC version. Usage: FDR56.

    • Order code 71324274

      Electronic insert D-AA2E, FDR56 (F34)

      Electronic module receiver. Non-hazardous area, 4-20mA, DC version. Usage: FDR56.

    • Order code 71324276

      Electronic insert D-AA3A, FDR56 (F34)

      Electronic module receiver. Non-hazardous area, solid-state-relay, AC version. Usage: FDR56.

    • Order code 71324277

      Electronic insert D-AA3E, FDR56 (F34)

      Electronic module receiver. Non-hazardous area, solid-state-relay, DC version. Usage: FDR56.

    • Order code 71324279

      Electronic insert D-BA1A, FDR56, V2

      Electronic module receiver. ATEX II 1/2D IP66 T102oC, relay, AC version. Compatible for devices that have been delivered from 01.05.2016 on. Usage: FDR56.

    • Order code 71324280

      Electronic insert D-BA1E, FDR56, V2

      Electronic module receiver. ATEX II 1/2D IP66 T102oC, relay, DC version. Compatible for devices that have been delivered from 30.04.2016 on. Usage: FDR56.

    • Order code 71324300

      Electronic insert D-BA1A, FDR56 (F34)

      Electronic module receiver. ATEX II 1/2D IP66 T102oC, relay, AC version. Usage: FDR56.

    • Order code 71324301

      Electronic insert D-BA1E, FDR56 (F34)

      Electronic module receiver. ATEX II 1/2D IP66 T102oC, relay, DC version. Usage: FDR56.

    • Order code 71324324

      Electronic insert D-BA2A, FDR56 (F34)

      Electronic module receiver. ATEX II 1/2D IP66 T102oC, 4-20mA, AC version. Usage: FDR56.

    • Order code 71324325

      Electronic insert D-BA2E, FDR56 (F34)

      Electronic module receiver. ATEX II 1/2D IP66 T102oC, 4-20mA, DC version. Usage: FDR56.

    • Order code 71324327

      Electronic insert D-BA3A, FDR56 (F34)

      Electronic module receiver. ATEX II 1/2D IP66 T102oC, Solid-state-relay, AC version. Usage: FDR56.

    • Order code 71324329

      Electronic insert D-BA3E, FDR56 (F34)

      Electronic module receiver. ATEX II 1/2D IP66 T102oC, Solid-state-relay, DC version. Usage: FDR56.

    • Order code 71324380

      Electronic insert D-IA1A, FDR56, V2

      Electronic module receiver. IECEx II 1/2D IP66 T102oC, relay, AC version. Compatible for devices that have been delivered from 01.05.2016 on. Usage: FDR56.

    • Order code 71324381

      Electronic insert D-IA1E, FDR56, V2

      Electronic module receiver. IECEx II 1/2D IP66 T102oC, relay, DC version. Compatible for devices that have been delivered from 01.05.2016 on. Usage: FDR56.

    • Order code 71324382

      Electronic insert D-IA1A, FDR56 (F34)

      Electronic module receiver. IECEx II 1/2D IP66 T102oC, relay, AC version. Compatible for devices that have been delivered from 01.05.2016 on. Usage: FDR56.

    • Order code 71324383

      Electronic insert D-IA1E, FDR56 (F34)

      Electronic module receiver. IECEx II 1/2D IP66 T102oC, relay, DC version. Compatible for devices that have been delivered from 01.04.2016 on. Usage: FDR56.

    • Order code 71324387

      Electronic insert D-IA2A, FDR56 (F34)

      Electronic module receiver. IECEx II 1/2D IP66 T102oC, 4-20mA, AC version. Usage: FDR56.

    • Order code 71324388

      Electronic insert D-IA2E, FDR56 (F34)

      Electronic module receiver. IECEx II 1/2D IP66 T102oC, 4-20mA, DC version. Usage: FDR56.

    • Order code 71324389

      Electronic insert D-IA3A, FDR56 (F34)

      Electronic module receiver. IECEx II 1/2D IP66 T102oC, Solid-state-relay, AC version. Usage: FDR56.

    • Order code 71324390

      Electronic insert D-IA3E, FDR56 (F34)

      Electronic module receiver. IECEx II 1/2D IP66 T102oC, Solid-state-relay, DC version. Usage: FDR56.

    • Order code 71113441

      接头 R1-1/2 + Rp1-1/2, 316Ti

      Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71113449

      接头 NPT1-1/2, 316Ti

      Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71113450

      延伸管 225mm, 高温适配器 R1-1/2 +

      Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71113451

      延伸 325mm, HT-adapter R1-1/2 +

      Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71113452

      延伸 525mm, HT-adapter R1-1/2 +

      Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71113453

      延伸 225mm, HT-Adapter NPT1-1/2

      Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71113454

      延伸 325mm, HT-adapter NPT1-1/2

      Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71113455

      延伸 525mm, HT-adapter NPT1-1/2

      Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 52017501

      安装支架

      Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 52017502

      安装支架

      Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71006345

      法兰

      Hole circle: 100mm. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71006346

      法兰

      Hole circle: 98.6mm. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71006348

      法兰

      EN1092-1, A. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71006349

      法兰

      ASME B16.5. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71006350

      法兰

      EN1092-1, A. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71006351

      法兰

      ASME B16.5. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71006352

      法兰

      EN1092-1, A. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71006353

      法兰

      ASME B16.5. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71026443

      焊接附件

      Screw assembling. Material: 316Ti, silicone. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71026444

      焊接附件

      Screw assembling. Material: 316Ti, silicone. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71026445

      焊接附件

      Screw assembling. Material: 316Ti, silicone. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71026446

      焊接附件

      Screw assembling. Material: 316Ti/321, silicone. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71026447

      焊接附件

      Screw assembling. Material: 316Ti/321, silicone. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71026448

      焊接附件

      Screw assembling. Material: 316Ti/321, silicone. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71026449

      法兰接头

      Screw assembling on counter flange. Material: 316Ti, PTFE, C4400. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71026450

      法兰接头

      Screw assembling on counter flange. Material: 316Ti, PTFE, C4400. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71026451

      法兰接头

      Screw assembling on counter flange. Material: 316Ti, PTFE, C4400. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71108383

      法兰

      EN1092-1,A. Inspection cert. EN10204-3.1 material (316Ti wetted parts). Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71108387

      法兰

      ASME B16.5. Inspection cert. EN10204-3.1 material (316Ti wetted parts). Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71108388

      法兰

      EN1092-1,A. Inspection cert. EN10204-3.1 material (316Ti wetted parts). Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71108389

      法兰

      ASME B16.5. Inspection cert. EN10204-3.1 material (316Ti wetted parts). Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71108390

      法兰

      EN1092-1,A. Inspection cert. EN10204-3.1 material (316Ti wetted parts). Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71108391

      法兰

      ASME B16.5. Inspection cert. EN10204-3.1 material (316Ti wetted parts). Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71209097

      玻璃视镜 DN100, 25bar, 200oC

      Installation on flange fitting. Material: borosilicate glass. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71209100

      玻璃视镜 DN80, 25bar, 200oC

      Installation on flange fitting. Material: borosilicate glass. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71209101

      玻璃视镜 DN50, 25bar, 200oC

      Installation on flange fitting. Material: borosilicate glass. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71209107

      玻璃视镜 DN100, 10bar, 200oC

      Installation on weld-in fitting. Material: borosilicate glass. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71209111

      玻璃视镜 DN80, 10bar, 200oC

      Installation on weld-in fitting. Material: borosilicate glass. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71209114

      玻璃视镜 DN50, 10bar, 200oC

      Installation on weld-in fitting. Material: borosilicate glass. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71209115

      玻璃视镜 DN100, 200oC

      Installation on weld-in fitting. Material: borosilicate glass. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71209116

      玻璃视镜 DN80, 200oC

      Installation on weld-in fitting. Material: borosilicate glass. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71209118

      玻璃视镜 DN50, 200oC

      Installation on weld-in fitting. Material: borosilicate glass. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71209119

      玻璃视镜 DN100, 6bar, 200oC

      Installation on screw-type fitting. Material: borosilicate glass. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71209121

      玻璃视镜 DN80, 6bar, 200oC

      Installation on screw-type fitting. Material: borosilicate glass. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.

    • Order code 71209122

      玻璃视镜 disc DN50, 6bar, 200oC

      Installation on screw-type fitting. Material: borosilicate glass. Usage: FDR50, FDR56/FDR57, FQR50, FQR56/FQR57, FTR20.
