CYM17 converter enables easy retrofit of conventional analog pH and oxygen sensor to Memosens CPS171D and COS81D in benchtop fermentation applications.
材质
Housing: Aluminum
外形尺寸
Height: 36.6 mm (1.44 in) Deep: 72 mm (2.8 in) Width 140.6 mm (5.5 in)
过程温度
-5 to 50 °C (20 to 120 °F)
防护等级
IP54
输入
M12 socket
输出
Output pH: mV signal according to Nernst equation with 0 mV at pH 7 and -59 mV/pH Temperature pH: simulated PT1000 Output oxygen: 0 to 60 nA with 60 nA at 100% oxygen saturation Temperature oxygen: simulated 22 kOhm NTC
测量原理
溶解氧传感器
应用
CYM17 converter enables easy retrofit of conventional analog pH and oxygen sensor to Memosens CPS171D and COS81D in benchtop fermentation applications.
材质
Housing: Aluminum
外形尺寸
Height: 36.6 mm (1.44 in) Deep: 72 mm (2.8 in) Width 140.6 mm (5.5 in)
过程温度
-5 to 50 °C (20 to 120 °F)
输入
M12 socket
输出
Output pH: mV signal according to Nernst equation with 0 mV at pH 7 and -59 mV/pH Temperature pH: simulated PT1000 Output oxygen: 0 to 60 nA with 60 nA at 100% oxygen saturation Temperature oxygen: simulated 22 kOhm NTC
