Technology Training PROFIBUS

A hands-on course, recognized in all industries

You will learn with the help of actual hands-on tasks, how PROFIBUS fieldbus technology works in detail. Features like device integration and device exchange are shown as well as device configuration via FDT/DTM.

日期

26.10.2021 - 27.10.2021

时间

08:30 - 17:00

地点

Endress+Hauser Process Solutions AG
Christoph Merian-Ring 12
CH-4153 Reinach
瑞士

在谷歌地图上查看

提供的语言

英语

最少参加人数

最多参加人数

费用(按本币计价)

800 CHF

learn more and sign up

附加信息

内容

In the theoretical part the following content is covered:
Organization of the PROFIBUS organization, PROFIBUS physical layer (DP, PA), types of wires and components, grounding and shielding concept.

FISCO, Ex-concepts, segment calculation (voltage, current loads, number of devices). PROFIBUS communication method, device drivers (GSDs).

Master / Slave principle, device integration procedure, bus parameters.

In the practical part the following content is covered:
Wiring of PROFIBUS DP and PA fieldbus segments, device integration, device configuration via FDT and PDM.Signal measurement with Bus analysis with the latest tools, procedures for troubleshooting, device replacement.

目标

At the end of the course you will be able to design and commission a PROFIBUS fieldbus network.

You will also understand the benefits of the technology and know the procedure for troubleshooting.

前提条件

Basic knowledge of electronics and ability to use a computer.

Participants are given time to work with the various components of a PROFIBUS fieldbus network.

We put emphasis on a balanced approach to theory and practice as well as a vendor-neutral atmosphere.

Mornings are spent learning the theoretical background and afternoons with the actual components and integration of the field devices into the system.

Almost half the course is spent on giving you ample opportunity to use what you have learned in hands-on tasks taken straight from our experience.
