Technology Training HART

A hands-on based course, recognized in all industries

You will learn with the help of actual hands-on tasks, how the HART technology works in detail. HART revisions, commands are discussed in theory parts. The different use cases and integration possibilities are trained in hands on sessions.

日期

04.05.2021

时间

08:30 - 17:00

地点

Endress+Hauser Process Solutions AG
Christoph Merian-Ring 12
CH-4153 Reinach
瑞士

在谷歌地图上查看

提供的语言

英语

最少参加人数

最多参加人数

费用(按本币计价)

350 CHF

Learn more and sign up

附加信息

内容

In the theoretical part the following content is covered:

History of HART communication

Possible ways to establish communication via HART

Point to point, Multidrop, Multiplexer, Remote I/O, Handheld

Frequency shift keying technology

Device addressing and range

HART commands and structure

HART telegram

HART revisions 5,6,and 7

Difference between the revisions

In the practical part the following content is covered:

Commissioning:

Using HART bus analyzer observing communication flow

Diagnosis :

Able to make appropriate suggestions about improving a customer`s physical layer

Able to connect HART handheld to device, reading out diagnostic (NE107)

Maintenance:

Able to integrate a field device into a DCS at a very basic level, reading out PVs via HART

Able to establish communication to the HART device via MultiPlexer and PROFIBUS Remote I/O

Able to configure HART device using FieldCare (FDT/DTM technology)

Able to wire up field devices in multidrop

Able to wire up an individual field device point to point

目标

At the end of the course you know different ways of using HART technology and able to design and commission a HART fieldbus network. You will also understand the benefits of the technology and know the procedure for troubleshooting.

前提条件

Basic knowledge of electronics and ability to use a computer.

资格

The training is Endress+Hauser certified.

评估方法

We put emphasis on a balanced approach to theory and practice as well as a vendor-neutral atmosphere.
The morning is spent learning the theoretical background and afternoons with the actual components and integration of the field devices into the system.
Almost half the course is spent on giving you multiple opportunities to use what you have learned in hands-on tasks taken straight from our experience.
