Proline Prosonic Flow P 500
超声流量计

超声流量计Proline Prosonic Flow P 500（9P5B），DN 80...4000 (3...156") ©Endress+Hauser

Proline Prosonic Flow P 500 – 超声流量计，捆绑式安装，适用于狭小空间应用

超声流量计Proline Prosonic Flow P 500（9P5B），DN 15...65 (½...2½") ©Endress+Hauser

Proline Prosonic Flow P 500安装在DN 15...65 (½...2½")口径的管道上

Prosonic Flow P 500，配备FlowDC功能

超声流量测量原理

  • 超声流量计Proline Prosonic Flow P 500（9P5B），DN 80...4000 (3...156")
  • 超声流量计Proline Prosonic Flow P 500（9P5B），DN 15...65 (½...2½")

超声流量计，搭配捆绑式传感器，可以安装在狭小空间内测量，适用于工业过程应用，最多支持3路输入/输出

Prosonic Flow P超声流量计传感器技术成熟，可以安装在管道弯头、扩径管或缩径管中稳定测量，测量精度不受外界因素的影响。捆绑式传感器采用非接触式测量方式，能够正常测量磨损性、腐蚀性或有毒流体。安装Prosonic Flow P 500，无需中断生产过程，也无需打开管道。采用Heartbeat Technology心跳技术，测量结果可靠，保证审计合规，同时还有助于确定最优安装位置。

Extended选型
  • F
  • L
  • E
  • X

  • 简易产品

  • 轻松执行仪表选型、安装和操作

仪表技术性能

选型便捷程度

  • 标准产品

  • 测量可靠、坚固耐用、低维护需求

仪表技术性能

选型便捷程度

  • 高端产品

  • 功能丰富，适用范围广

仪表技术性能

选型便捷程度

  • 定制产品

  • 专门针对严苛工况设计

仪表技术性能

选型便捷程度

特殊选型

FLEX产品选型 仪表技术性能 选型便捷程度
  • F
  • L
  • E
  • X

Fundamental选型

完美胜任基本测量任务

仪表技术性能
选型便捷程度
  • F
  • L
  • E
  • X

Lean选型

轻松应对关键工艺的测量挑战

仪表技术性能
选型便捷程度
  • F
  • L
  • E
  • X

Extended选型

创新技术助力工艺流程优化

仪表技术性能
选型便捷程度
  • F
  • L
  • E
  • X

Xpert选型

满足严苛工况的特殊测量要求

仪表技术性能
选型便捷程度

特殊选型

此产品暂未在中国市场销售

  • 产品规格参数

    • 最大测量误差

      Volume flow:
      ±3% o.r. for DN15
      ±2% o.r. for DN25 to DN200
      ±2% o.r. above DN200

    • 测量范围

      0 to 15 m/s (0 to 50 ft/s)

    • 介质温度范围

      DN15 to 65 (½to 2½"): -40 to +150°C (-40 +302 °F)
      DN50 to 4000 (2…160"): -40 to +170°C (-40 +338 °F)

    • 最大过程压力

      N/A

Loading alternative products

快速选择

从我们建议的选项中选择
售价
    -- selected coding
    -- selected label
    99.999,00
    <%label%>
    -- selected coding
    -- selected label
    99.999,00
    <%feature%>
  • Process Connection
      <%label%>
      99.999,00
      <%label%>
      99.999,00

  • <%message%>

9P5B
显示详细信息 隐藏详细信息
显示详细信息
返回进行快速选择
  • <%feature%>
    <%coding%>
    <%label%>
pc
价格核算中…
暂时无价格信息
from CHF 803.-
  • 可选附加功能
请使用 Configurator进行完整产品选型
或

个性化配置

从所有可用选项中继续选择

  • 优势

    • 稳定测量：配备FlowDC功能，即使前直管段长度较短，测量精度也完全不受影响

    • 符合高安全标准：SIL设计，通过国际防爆认证

    • 信号长期稳定性高：安装在管道外部，免维护

    • 安装在不同材质的管道上均能可靠测量：GRP管道和塑料管道

    • 提供完整的过程和诊断信息：多种用户自定义I/O组合方式

    • 降低复杂性和多变性：允许用户自定义输入/输出功能

    • 自带校验功能：采用Heartbeat Technology心跳技术

  • 应用领域

    • 非接触式测量原理，不受压力、密度和电导率的影响

    • 支持双向液体流量测量，例如液态烃和化学品，应用广泛

    仪表特点:

    • 直接外部安装，无需中断生产过程

    • 宽公称口径范围：DN 15...4000 (½...160")

    • 介质温度：–40...+170 °C (–40...+338 °F)

    • 分体型仪表，最多带3路输入/输出

    • 背光显示屏，触摸键操作，允许WLAN访问

    • 标准电缆连接传感器和变送器

特征和规格

返回

Details

  • 测量原理

    超声波流量测量

  • 产品标题

    Flowmeter for hazardous area installations with a wide range of analog and digital outputs.
    Automatic frequency scan for maximum measuring performance.
    Ideal clamp-on device for applications with chemicals, solvents, liquid hydrocarbons, acids, alkalis.

  • 传感器特点

    Increased safety for chemical and petrochemical industry – international hazardous area approvals. Long-term stable signal – maintenance-free permanent mounting from outside with coupling pads. Process transparency – diagnostic capability.
    Medium temperature: –40 to 170 °C (–40 to 338 °F). Wide nominal diameter range: DN 15 to 4000 (½ to 160"). Process piping unaffected by meter installation.

  • 变送器特点

    Highest performance – extended functionality and diagnostics. Flexible data transfer options – numerous communication types. Automatic recovery of data for servicing.
    Aluminium transmitter housing. 4‐line backlit display with touch control. HART, PROFIBUS PA/DP, FOUNDATION Fieldbus.

  • 公称口径范围

    Dual channel, 1 or 2 paths : DN15 to 4000 (1/2 to 160")

  • Sensor materials

    Clamp on system:
    Sensor holder 1.4301/304, 1.4404/316L
    Sensor housing 1.4301/304, 1.4404/316L
    Strapping bands 1.4301/304, 1.4404/316L

  • 测量变量

    Volume flow, sound velocity, flow velocity, totalizer

  • 最大测量误差

    Volume flow:
    ±3% o.r. for DN15
    ±2% o.r. for DN25 to DN200
    ±2% o.r. above DN200

  • 测量范围

    0 to 15 m/s (0 to 50 ft/s)

  • 最大过程压力

    N/A

  • 介质温度范围

    DN15 to 65 (½to 2½"): -40 to +150°C (-40 +302 °F)

    DN50 to 4000 (2…160"): -40 to +170°C (-40 +338 °F)

  • 环境温度范围

    -40 to +60 °C (-40 to +140 °F)
    -50 to +60 °C (-58 to +140 °F) optional

  • 传感器外壳材质

    N/A

  • 变送器外壳材质

    AlSi10Mg, coated; 1.4409 (CF3M) similar to 316L

  • 防护等级

    Sensor remote version: IP68 type 6P
    Transmitter remote version: IP66/67, Type 4X enclosure

  • 显示/操作

    4-line backlit display with touch control(operation from outside)
    Optional: WLAN
    Configuration via local display and operating tools possible

  • 输出

    3 outputs:
    4-20 mA HART (active/passive)
    4-20 mA (active/passive)
    Pulse/frequency/switch output (active/passive)
    Double pulse output (active/passive)
    Relay output

  • 输入

    Status input
    4-20 mA input

  • 数字通信

    HART, Modbus RS485

  • 电源

    DC 24 V

    AC 100 to 230 V

    AC 100 to 230 V / DC 24 V (non-hazardous area)

  • 防爆认证

    ATEX, FM/CSA

  • 其他认证和证书

    其他认证和证书

  • 产品安全性

    CE, C-tick

  • 功能安全性

    Functional safety according to IEC 61508, applicable in safety-relevant applications in accordance with IEC 61511

  • 计量认证和证书

    Flowmeter verification for DN15, 25, 40, 50 & 100
    Calibration performed on accredited calibration facilities (acc. to ISO/IEC 17025)

    Heartbeat Technology complies with the requirements for measurement traceability according to ISO 9001:2015 – Section 7.1.5.2 a

  • 船级认证和证书

    Marine certificate

文档/手册/软件

附件/备件

Nr
Order code
Specification
  • 31
  • 33
    • Nr 33 Order code XPD0090-

      ISEM, Prosonic Flow P 500, nEx/Z2

      Usage: Valid for approvals acc. feature 010. Consists of: ISEM (sensor electronic module) V304-02. Usage: Valid for approvals acc. feature 010. Consists of: ISEM (sensor electronic module) V304-02.

  • 39
  • 33
    • Nr 33 Order code XPD0091-

      ISEM, Prosonic Flow P 500, Ex

      Usage: Valid for approvals acc. feature 010. Consists of: ISEM (sensor electronic module) V304-01. Usage: Valid for approvals acc. feature 010. Consists of: ISEM (sensor electronic module) V304-01.

  • 37
    • Nr 37 Order code 71323010

      模块盒, 300/500, Ex

      Usage: transmitter housing, electronic compartment. Consists of: module cartridge incl. interconnection board.

  • 34
  • 37
    • Nr 37 Order code 71323011

      模块盒, 300, Non-haz

      Usage: transmitter housing, electronic compartment. Consists of: module cartridge incl. interconnection board.

  • 46
  • 35
  • 45
    • Nr 45 Order code 71323073

      接线端子组件

      Usage: transmitter housing Alu/hygienic, connection compartment. Option A = HART, PROFIBUS PA, FOUNDATION Fieldbus. Consists of: 1x connection terminal 2-Pol., 1x connection terminal 3-Pol., 1x connection terminal 4-Pol.

  • 50
  • 45
    • Nr 45 Order code 71327818

      接线端子组件

      Usage: transmitter housing Alu/hygienic, connection compartment. Option C = PROFIBUS DP, Modbus RS485. Consists of: 1x connection terminal 2-Pol., 1x connection terminal 3-Pol., 1x connection terminal 4-Pol.

    • Nr 45 Order code 71323075

      接线端子组件

      Usage: transmitter housing Alu/cast, connection compartment. Option A = HART, PROFIBUS PA, FOUNDATION Fieldbus. Consists of: 2x connection terminal 2-Pol., 1x connection terminal 4-Pol.

    • Nr 45 Order code 71327819

      接线端子组件

      Usage: transmitter housing Alu/cast, connection compartment. Option C = PROFIBUS DP, Modbus RS485. Consists of: 2x connection terminal 2-Pol., 1x connection terminal 4-Pol.

  • 20
    • Nr 20 Order code 71323016

      盖组件

      Usage: Promag/Promass/Prosonic Flow/t-mass 300, Prosonic Flow 500, transmitter housing Alu, Non-haz. Promag/Promass 300, Promag/Promass/Prosonic Flow 500, transmitter housing Alu, Ex. Consists of: cover sight glass, Alu, O-Ring 110.7x3.53 HNBR.

    • Nr 20 Order code 71323017

      盖组件

      Usage: Promass/Prosonic Flow/t-mass 300, transmitter housing Alu, Non-haz. Promass 300, Promag/Promass/Prosonic Flow 500, transmitter housing Alu, Ex. Consists of: cover sight glass, Alu, O-Ring 110,7x3,53 FVMQ, -50oC/-58oF.

    • Nr 20 Order code 71323020

      铝盖组件 玻璃视窗

      Usage: Promag/Promass/Prosonic Flow/t-mass 300, Promag/Promass/Prosonic Flow 500, transmitter housing Alu, Ex. Consists of: cover sight glass, Alu, O-Ring 110.7x3.53 HNBR.

    • Nr 20 Order code 71323021

      盖组件

      Usage: Promass/Prosonic Flow/t-mass 300, Promag/Promass/Prosonic Flow 500, transmitter housing Alu, Ex. Consists of: cover sight glass, Alu, O-Ring 110,7x3,53 FVMQ, -50oC/-58oF.

    • Nr 20 Order code 71323024

      盖组件

      Usage: Promass/Prosonic Flow 300, Promag/Promass/Prosonic Flow 500, transmitter housing cast, Ex. Consists of: cover sight glass, cast, O-Ring 110.7x3.53 HNBR.

    • Nr 20 Order code 71323025

      盖组件

      Usage: Promass/Prosonic Flow 300, Promag/Promass/Prosonic Flow 500, transmitter housing cast, Ex. Consists of: cover sight glass cast, O-Ring 110,7x3,53 FVMQ, -50oC/-58oF.

  • 70
    • Nr 70 Order code 71323026

      盖组件

      Usage: Promag/Promass/Prosonic Flow/t-mass 300, Promag/Promass/Prosonic Flow 500, transmitter housing Alu/cast. Consists of: 10x O-Ring 110.7x3.53 HNBR.

    • Nr 70 Order code 71323027

      盖组件

      Usage: Promass/Prosonic Flow/t-mass 300, Promag/Promass/Prosonic Flow 500, transmitter housing Alu/cast, Consists of: O-Ring 110,7x3,53 FVMQ, -50oC/-58oF.

  • 22
    • Nr 22 Order code 71323028

      盖组件

      Usage: Promag/Promass/Prosonic Flow/t-mass 300, Prosonic Flow 500, transmitter housing Alu, Non-haz. Consists of: cover Alu, O-Ring 117,1x3,53 HNBR.

    • Nr 22 Order code 71323029

      盖组件

      Usage: Promass/Prosonic Flow/t-mass 300, Prosonic Flow 500, transmitter housing Alu, Non-haz. Consists of: cover Alu, O-Ring 117,1x3,53 FVMQ, -50oC/-58oF.

  • 74
    • Nr 74 Order code 71323030

      盖组件

      Usage: Promag/Promass/Prosonic Flow/t-mass 300, Prosonic Flow 500, transmitter housing Alu, Non-haz. Consists of: 10x O-Ring 117,1x3,53 HNBR.

    • Nr 74 Order code 71323031

      盖组件

      Usage: Promass/Prosonic Flow/t-mass 300, Prosonic Flow 500, transmitter housing Alu, Non-haz. Consists of: O-Ring 117,1x3,53 FVMQ, -50oC/-58oF.

  • 22
    • Nr 22 Order code 71323032

      盖组件

      Usage: Promag/Promass/Prosonic Flow/t-mass 300, Promag/Promass/Prosonic Flow 500, transmitter housing Alu, Ex. Consists of: cover Alu, O-Ring 120,2x3,53 HNBR.

    • Nr 22 Order code 71323033

      盖组件

      Usage: Promass/Prosonic Flow/t-mass 300, Promag/Promass/Prosonic Flow 500, transmitter housing Alu, Ex. Consists of: cover Alu, O-Ring 120,2x3,53 FVMQ, -50oC/-58oF.

    • Nr 22 Order code 71323034

      盖组件

      Usage: Promass/Prosonic Flow 300, Promag/Promass/Prosonic Flow 500, transmitter housing cast, Ex. Consists of: cover cast, O-Ring 120,2x3,53 HNBR.

    • Nr 22 Order code 71323035

      盖组件

      Usage: Promass/Prosonic Flow 300, Promag/Promass/Prosonic Flow 500, transmitter housing cast, Ex. Consists of: cover cast, O-Ring 120,2x3,53 FVMQ, -50oC/-58oF.

  • 74
    • Nr 74 Order code 71323036

      盖组件

      Usage: Promag/Promass/Prosonic Flow/t-mass 300, Promag/Promass/Prosonic Flow 500, transmitter housing Alu/cast, Ex. Consists of: 10x O-Ring 120,2x3,53 HNBR.

    • Nr 74 Order code 71323037

      盖组件

      Usage: Promass/Prosonic Flow/t-mass 300, Promag/Promass/Prosonic Flow 500, transmitter housing Alu/cast, Ex. Consists of: O-Ring 120,2x3,53 FVMQ, -50oC/-58oF.

  • 23
    • Nr 23 Order code 71323038

      盖组件

      Usage: Promag 10, Promag/Promass/Prosonic Flow 500, wall mount transmitter Alu, connection compartment. Consists of: cover Alu, O-Ring 88,50x3,53 HNBR.

    • Nr 23 Order code 71323039

      盖组件

      Usage: Promag/Promass/Prosonic Flow 500, wall mount transmitter Alu, Ex, connection compartment. Consists of: cover Alu, O-Ring 88,50x3,53 FVMQ, -50oC/-58oF.

    • Nr 23 Order code 71323040

      盖组件

      Usage: Promag/Promass/Prosonic Flow 500, wall mount transmitter cast, Ex, connection compartment. Consists of: cover cast, O-Ring 88,50x3,53 HNBR.

    • Nr 23 Order code 71323041

      盖组件

      Usage: Promag/Promass/Prosonic Flow 500, wall mount transmitter cast, Ex, connection compartment. Consists of: cover cast, O-Ring 88,50x3,53 FVMQ, -50oC/-58oF.

  • 75
    • Nr 75 Order code 71323042

      盖组件

      Usage: Promag 10, Promag/Promass/Prosonic Flow 500, wall mount transmitter Alu/cast, connection compartment. Consists of: 10x O-Ring 88,50x3,53 HNBR.

    • Nr 75 Order code 71323043

      盖组件

      Usage: Promag/Promass/Prosonic Flow 500, wall mount transmitter Alu/cast, Ex, connection compartment. Consists of: O-Ring 88,50x3,53 FVMQ, -50oC/-58oF.

  • 71
    • Nr 71 Order code 71323071

      界面密封圈组件

      Usage: Promass/Prosonic Flow/t-mass 300, Promass/Prosonic Flow 500, transmitter housing/sensor or transmitter housing/wall mount. Consists of: 5x O-Ring 88,50x3,53 HNBR for interface.

    • Nr 71 Order code 71323072

      界面密封圈组件

      Usage: Promass/Prosonic Flow/t-mass 300, Promass/Prosonic Flow 500, transmitter housing/sensor or transmitter housing/wall mount. Consists of: O-Ring 88,50x3,53 FVMQ for interface, -50oC/-58oF.

  • 11
    • Nr 11 Order code 71368488

      保护壳

      Usage: transmitter housing Alu/hygienic, connection compartment. Option A = HART, PROFIBUS PA, PROFIBUS DP, Modbus RS485, FOUNDATION Fieldbus. Consists of: Connection compartment protective cover, display carrier, 2x screw M4x10.

    • Nr 11 Order code 71323081

      保护盖组件

      Usage: transmitter housing Alu/cast, connection compartment. Option A = HART, PROFIBUS PA, PROFIBUS DP, Modbus RS485, FOUNDATION Fieldbus. Consists of: Connection compartment protective cover, display carrier, 2x screw M4x10.

  • 87
    • Nr 87 Order code 71343505

      防护外壳组件

      Usage: Promag/Promass/Prosonic Flow/t-mass 300, Promag/Promass/Prosonic Flow 500, transmitter housing. Consists of: weather protection cover 4404, installation material.
